Automatic M Fold Paper Towel Machine, M Fold Paper Towel Making
Machine
Application
This ACE-M240-6L Automatic M Fold Paper Towel Machine, M Fold Paper Towel Making
Machine is with steel to steel embossing unit and lamination system. It is
good quality high speed tissue converting machine to manufacture M
fold interfolded paper towels, four folds paper towels, five folds
paper towels, six folds paper towels and nonwoven airlaid tissue,
and MG paper napkins etc. It is with the out-of-date latest
technology in tissue paper converting. It adopts vacuum folding
style. The mainly function of this machine is to manufacture
commercial tissue paper products and away-from-home tissue paper
products, easy-to-take one by one plain, embossed and LOGO printed
and colored and laminated interfolded M W fold paper hand towels.
It is an ideal equipment to manufacture high grade away-from-home
customized embossed facial tissue paper napkin products.
Advantage:
1 Machine for M fold paper hand towels
2 With glue lamination unit.
3 high speed up to 6000 sheet/min
4 Energy-saving.
5 Vacuum fold
6 Fold stype: M fold, Four fold, Five fold, Six fold.
Quick details:
1 Cylinder cutoff size: 240mm or customized etc.
2 Lamination system.
3 with 6lanes
4 Interfolded and M fold
5 Can connect to logsaw cutting machine
Technical parameters as below
| Model | ACE-M240-6L |
| Output type | Automatic M Fold Paper Towel Machine, M Fold Paper Towel Making
Machine |
| Folding speed | 1000 piece/min/lane * 6lanes = 6000 sheet/min, depending on the
paper quality and napkin size. |
| Raw paper | 13-20g/m2 2-ply, 16-45g/m2 1-ply, wooden pulp paper or MG paper or
nonwoven airlaid. Other sizes please specify. |
| Jumbo roll size | ≤ 1200mm x Φ1200mm (Depends on your napkin size, customized) |
| Napkin size | Open size: 240±2mm x 200mm Other size, please specify. Folded size: 80±2mm x 200mm Fixed cutoff cylinder size is 240m. Other size available, please
specify. or Customized. |
| Folding type | Inter folding Vacuum fold W M fold, Four fold, Five fold, Six fold, 4 folds, 5 folds, 6 folds |
| Embossing unit | 1- Steel to steel. 2- Embossing pattern can be any LOGO, brand name, flowers etc. 3- Embossing pattern can be customized by client or recommended by
us 4- Controlled by screws, mechanical pressing type. Cylinder type is optional. |
| Point to point Lamination system | a. With 2 complete sets of point to point lamination units. b. The whole design is copied Italy design. c. Heavy chrome coating roll d. Micro-adjustment of nips between the steel roll e. Anilox roll for glue applicant. f. Controlled by cylinders g. Each lamination unit controlled by an independent reducer. When
the machine stops, the motor will start running to rotate the
anilox roll to prevent it getting dry. |
| Tension control | Speedless Tension control unit to fit the machine for paper of
different quaity and different gsm. With automatic web guiding system. With automatic web tension control system. |
| Videos and photos available. |
l. Important parts:
Taiwan DELTA or Germany Siemens PLC + touch screen + inverter.
Japan Omron sensors.
France Schneider electronics like contactors, relay and breakers.
The best China bearings. (Even Japan NSK or Sweden SKF bearings for
the main rollers.).
Taiwan Airtac cylinders and air switch.
Taiwan vacuum pump, less noise and power.
Jiangsheng brand motors made in China.
D. Important parts:
1. Taiwan DELTA Inverter. Much easier for operation. (Other
companies use only buttons and even all inferior buttons, easy to
damage. And they use Elctromagnetic speed control, easy to get
broken.)
2. Japan Omron sensors for detecting paper break. (Other companies
use inferior brands)
3. Franch Schneider electrical parts like breakers, contactors and
relays. (Other companies inferior brands made in China)
4. French Schneider buttons (Other companies use bad quality
buttons)
5. The best China bearings, even Japan NSK bearings for the main
aprts. (Other companies use cheap inferior brands bearings)
6. Taiwan Airtac cylinders. (Other companies use not that good
brand)
7. The best brand motor made in China. (Other companies inferior
brand)
8. Stronger structure and better quality parts than others.
Complete thickened wallboard steel plate structure to ensure high
speed running, no vibration.
H. Control system
a. Speed: about 1000 piece/min/lane x 6 lanes. Depends on paper
quality, workers etc.
b. Speed of production is controllable.
c. Main motor control by inverter
d. Automatic left-right stagger counting system, each stack of 100
pieces, 150pieces etc.
e. Machine will automatically stop if paper break or paper jams.
f. Power: about 7.5KW for main motor 3-phase AC380V 50HZ or
customized.
g. With Taiwan vacuum pump, about 18.5KW. (Taiwan brand)
h. Vacuum pump for adsorption (included in quotation.)
i. Air pressure: 0.5Mpa(buyer supplied)
j. Machine weight: 6000kg.
k. Machine size: about 6000x1000x2100mm.
Finished products of this Automatic M Fold Paper Towel Machine, M Fold Paper Towel Making
Machine:
